CAMERA MONITOR SYSTEM

CMS vision
for commercial vehicles

Class II / IV and Class V / VI monitors and cameras form MA-E24 and MA-E56 Camera Monitor System configurations for commercial vehicles.

Explore products↗ Talk to us→

Discover more

10+Years of automotive R&D

4CMS · MOIS · BSIS · REIS

6MA-E24 / MA-E56 configurations

−40–85°CCamera operating range

PRODUCT MATRIX

MA-E24 and MA-E56
system configurations

Six configurations cover Class II, IV, V and VI fields of view, with BSIS, MOIS and REIS integrated in designated configurations.

View all products ↗

System Solutions

MA-E24 Camera Monitor System

Class II / IV rear-view CMS with optional Class V coverage and BSIS.

↗

System Solutions

MA-E56 Integrated Safety System

Class V / VI visibility with optional BSIS, MOIS and REIS integration.

↗

CMS Monitors

Class II & IV CMS Monitor

12.3 or 14.5-inch IPS TFT, 1920×720 resolution and automatic or manual backlight.

↗

CMS Monitors

Class V & VI CMS Monitor

10.1-inch IPS TFT at 1920×720 for close-proximity and front blind-zone views.

↗

Vehicle Cameras

Class II & IV CMS Camera

SONY ISX031, 1920×1536 at 60 fps, 120 dB WDR and IP69K protection.

↗

Vehicle Cameras

Class V / VI & REIS Camera

AHD 1080P wide-angle camera with 0.01 Lux minimum illumination and 2D / 3D DNR.

↗

Installation cases

Four
installation cases

Installation cases cover YT bus, GD bus, ZT coach and motorhome applications, including exterior cameras and in-cab displays.

YT bus

Vehicle, exterior camera and vertical in-cab display.

↗

GD bus

Vehicle, exterior camera and split-screen in-cab display.

↗

ZT coach

In-cab display and dual exterior-camera installation.

↗

Motorhome

Motorhome and vertical side-rear cockpit display.

↗

CAMERA PROTECTIONIP69K

WDR · 120 dB

FULL-COLOUR NIGHT VISION

Product capability

Features for a clear
field of vision

Product features include WDR, full-colour night vision, anti-glare, hydrophilic technology, mirror / normal image, optional heating and optional BSD. Camera protection reaches IP69K.

✓Up to 120 dB WDR
✓IP69K protection
✓Full-colour night vision

PRODUCTION & TECHNICAL TESTS

Manufacturing capacity
and technical testing

Manufacturing capacity includes annual PCBA shipments of 100 million pieces, 25 AI lines, 40 SMT lines, 90 DIP lines, four lithium-battery packaging lines and four complete production lines. Technical-test equipment covers EMC, thermal shock, temperature / humidity and transient pulse / surge testing.

100MPCBA annual shipments

40SMT production lines

25AI production lines

90DIP production lines

MANUFACTURING FLOOR 25 AI · 40 SMT · 90 DIP

Technical test equipment

01EMC shielding room, EMI and transmission receivers
02Thermal shock and temperature / humidity chambers
03Transient pulse / surge voltage tester and static meter
04Explosion-proof high / low-temperature chamber, lithium-battery reliability tester and cell tester

ECER10 / R46CMS CERTIFICATION

ABOUT US

More than 10 years of automotive R&D experience

Guangzhou Aimiro Technology Co., Ltd. is a high-tech enterprise specializing in Camera Monitor Systems. Products have been sold to China, Germany, France, Italy, Israel, Russia, Mexico and Arabic-speaking markets.

Know more↗

COOPERATION EXPERIENCE

Cooperation experience in
China, Germany and Israel

Cooperation experience covers vehicle manufacturers in China, Germany and Israel. Products have been sold to China, Germany, France, Italy, Israel, Russia, Mexico and Arabic-speaking markets.
